Tektor 2200 ohms
Trimm R-2-A Sig
Corps Trimm Professional 4K ohms,
nice brown swirl Bakelite
Tektor courtesy of Ken Harthun
TBH
Junior
Eugent T.
Turney
Little Tattler by Marinette
Triangle
Electric
Thomas
Teleradio Engineering Corp
Some Notes on the above headsets:
Trimm was one of the longest lived makers of headphones, starting
with the Trimm Dependables with aluminum housings in the 1920's,
and going to the bakelith cans somewhere in the 1940's I think.
The ones with cloth headbands were earlier and they went to the
vinyl coated headbands probably in the 1950's or 60's. They were
available in a variety of impedances from 8 ohms up to 4000 ohms.
They also made the Featherweights in 5K 4K, 2K and 100 ohm
impedance as well as the Commercials in 3K impedance, and perhaps
more. Trimm also manufactured headphones for other brand names
such as the Rex, and from the construction many others. They were
good consumer grade headphones and I still use them for crystal
radio listening. The Trimm Professionals that I have come across
were either the plain black cans, or a nice swirl brown bakelite
in the 4000 ohms DC resistance. These have very good sensitivity
and are quite attractive if in good condition. Trimm also made a
variety of military headphones such as the R-2-A ( a nice 2K
headset like WE 509), Type W 600 ohm impedance, and Type K 2200
ohm resistance nice for crystal radio listening.
Little Tattlers by Marinette were nice looking 1000 ohm economy grade headphones that were cheaply made and the earcaps tended to crack, but most sets I have had are still in working condition, though the one piece center pole magnet tends to lose its strength and is difficult to remagnetize. Sensitivity only fair at best for crystal radio listening though they are cheap and will work on locals or a battery set.
The Eugent Turney, Teleradio, TBH, and Traingle headsets
are all mid 1920's and are well made headsets. The Triangle are
fairly common and the other 2 are uncommon.
The Thomas headset is probably 1950's vintage and cheaply made.
The Teleradio headset is the only example of this maker I have
seen.
Email to scottswim@aol.com
Back
to Scott's Crystal Radios home page
Back to Headphone Gallery Home page
TBH Headphones from Radio Magazine, May 1924
